Electrical Tar Precipitator

The electric tar precipitator is an advanced environmental protection equipment that utilizes high-voltage direct current electric field technology to efficiently separate tar droplets from gases, thereby improving the cleanliness of gas emissions during the coking process. Its unique design effectively reduces environmental pollution and ensures more environmentally friendly operation of the coke oven.

Introduction

The electrical tar precipitator is a device that uses the effect of a high-voltage direct current electric field to separate tar droplets from gas or coke oven gas in the initial cooling equipment. The structure of the electrical tar precipitator can be divided into three types: concentric circle type, tube type, and honeycomb type.

Working principle

A 40-60 kV electric field is established between the settling electrode and the corona electrode. Corona discharge occurs in the space between the two electrodes. When gas containing dust or tar droplets passes through this space, the dust and tar droplets are polarized and charged, moving towards the settling electrode and adhering to the wall of the settling electrode tube when they collide with it. Due to their weight, the tar droplets sink to the bottom of the electrical tar precipitator, where they are captured. The captured tar is similar in viscosity to heavy oil, so a heating coil is installed at the bottom of the electrical tar precipitator to ensure smooth discharge.

product-1024-768

Electrical tar precipitator technical parameters

Specification		FD37	FD48	FD55	FD61	FD73	FD85	FD91	FD97	FD109	FD114	FD121		FD144
diameter(mm)		1970	2260	2380	2500	2700	2830	3000	3000	3200	3340	3340		3620
Effective cross-sectional area(m2)		1.82	2.36	2.70	2.99	3.58	4.17	4.47	4.76	5.35	5.60	5.94		7.07
Processing capacity(m3/h)	upper limit	3700	4800	5500	6100	7300	8500	9100	9700	11000	11500	12000		14000
Processing capacity(m3/h)	lower limit	5200	6800	7700	8500	10000	12000	13000	14000	15000	16000	17000		20000
Number of precipitation poles		37	48	55	61	73	85	91	97	109	114	121		144
Matching Power Supply kV/mA		72/150	72/150	72/150	72/20	72/20	72/250	72/250	72/300	72/300	72/300		72/350	72/350
Inlet temperature(℃)		100～120
Precipitator inner diameter(mm)		250
Operating Voltage KV		40～60
